All Cambria quartz surface products comply with the requirements in the Build America Buy America and Buy American Acts
Series Name
Coordinates Collection
Warranty
A transferable Full Lifetime Warranty is available, which lasts the entire length of the product’s life, and is transferable to subsequent owners. Refer to Warranty PDF for more information
Manufacturer Notes
Variations in natural quartz stone color, pattern, size, shape, and shade are unique and inherent characteristics of this product. Material samples are small selections cut from a slab and do not fully show all design characteristics of a slab or the final installed product. Prior to purchase, view a larger representation of a design. Pot holders and trivets should be used to protect a quartz countertop from anything hot, as the material can be damaged by sudden changes in temperature
Material & Finish
Construction
Pure quartz, pigments, and binders are agglomerated, heated, and cast into through-body color slabs
Content
Quartz, binder, and pigment
Finish
Polished and Cambria Satin
Format
Slab
Surface Sheen
Polished
Availability & Procurement
Availability
Typically Stocked, Confirm Stock Level with Sales Rep
City Of Origin
LeSueur
Country Of Origin
United States
Custom Capabilities
Custom designs and dimensions available upon request
Lead Time
Contact your rep for lead times
Technical Specifications
Impact Resistance
Passes ASTM F-3007 (2 cm Only)
Length
132
Overall Thickness
3
Size
132 in x 65.5 in (Jumbo). Check with your local rep/ installer/fabricator for slab size availability per design, includ ing the largest size able to be fabricated versus slab size listed
Total Weight
5lbs/ft2 (24 kg/m2) for 1 cm, 10 lbs/ft2 (48 kg/m2) for 2 cm, and 15 lbs/ft2 (72 kg/m2) for 3 cm
Install in accordance with brand’s instructions on approved shop drawings; to be done by an approved installer, certified in writing. Cut and polish with water-cooled powered tools. Any cutouts shall have a minimum of 0.25in radius. For horizontal surfaces, apply a continuous bead of adhesive at the intersection point of the countertop and the substrate or cabinet. This bead will be continuous throughout the entire perimeter. Allow gaps for expansion of no less than 0.125in per 10ft when installed between walls or other fixed structures. Can be thermoformed to a 120 in minimum inside radius. Restrictions and limitations vary for designs and thicknesses
Recommended Adhesive
Structural grade 50-year 100% silicone or epoxy adhesive for mounting. Adhesive that will be visible in finished work shall be tinted to match quartz surface. Cambria’s adhesives for setting seams in countertops are GREENGUARD approved.
Suitable Substrates
Not a structural support material and must be supported in every application
