Milliken Urban Sketch | Product

Core Specs

General Information

Collection Name: Comfortable Concrete
Color Name: URS119-106 Pitch Black
Manufacturer SKU: 4000288901
Price Range: $$$
Product Name: Urban Sketch
Sample Note: Intended for commercial project specification only. Specify the number of M² within your project in order to better assist you.
Warranty: Lifetime Commercial Warranty. Refer to Warranty attachment for details

Material & Finish

Backing: PVC-Free WellBAC® Comfort Cushion
Carpet Fiber Type: Type 6 6 Nylon
Construction: Tufted, Textured Loop
Content: Milliken-Certified WearOn® Nylon
Dye Method Filter: Digital Dye Injection / Printed
Finish: StainSmart®
Format: Modular

Availability & Procurement

Availability: Typically Stocked, Stocked in North America
City Of Origin: LaGrange
Country Of Origin: United States
Custom Capabilities: Avaliable with TractionBack® (an NSF 140 Platinum backing option)
Manufacturing Location: La Grange, GA

Technical Specifications

Length: 19.7
Overall Thickness: 7.9
Product Features: Customizable
Yarn Tuft Details: 1/10 Gauge, 14.4 SPI, 144/ sq in (2,230/100 sq cm) Tufts

Applications & Usage

Application Filter: Flooring
Installation: Glue down. Refer to Installation attachment for details
Installation Direction: Ashlar

Performance Metrics

Crocking: AATCC 165 = 4.0 Wet or Dry
Durability: Contract (Severe Traffic)
Electrostatic Propensity: AATCC 134 Static Electricity (20% R.H.,70° F) = 3.5 kV, Permanent Conductive Fiber
Flammability: ASTM E648 Radiant Panel = 0.45, Class l; ASTM E662 (NFPA 258T) Smoke Density = 450; ASTM D2859 (CSPC FF-1-70) Methenamine Pill Test - Self-Extinguishing
Light Blocking: Complete
Lightfastness: AATCC 16E = 4.0 at 80 Hours
Maintenance: MilliCare® Textile and Carpet Care Service Network

Sustainability

Human Health

VOC Emissions Testing Methodology: CDPH / CHPS 01350 Compliant

Climate Health

Emissions: TVOC Range - 0.5 mg/m³ or less; Embodied Carbon - 13.39 (kg CO2e)/m²
GWP Functional Unit: kg CO2e/m2
LCA Optimization Plan: false

Social Health & Equity

Organizational Commitments: Carbon Disclosure Project, ISO 14001, Science Based Targets Initiative (SBTI)
Sustainability Action Plan: Sustainability Action Plan

Certifications & Disclosures

Disclosure Level: 100 ppm
Environmental Product Declaration: Product-Specific EPD
Ingredient Disclosure: Health Product Declaration (HPD)
LEED: May contribute to LEED credits
VOC Emissions Testing Certificate: CRI Green Label Plus
