Cube panels are customizable with Print, Mold & Press, Precision Cut, Groove, and Peel ‘n’ Stick, and require no edging or capping
Technical Specifications
Impact Resistance
ISO 7892:1988. Hard body: resists 9J (0.5kg/2m); no surface damage. Soft body: resists 70J (50kg/150mm); no damage. Adhered to 10mm plasterboard.
Length
164
Overall Thickness
0.16
Size
4 ft x 36 ft
Applications & Usage
Application Filter
Ceiling|Wall
Recommended Adhesive
Contact-type adhesive suitable for most common substrates; consult adhesive supplier with product samples and substrate specification. SpinFix™ adhesive-free mounting clips available as alternative.
Suitable Substrates
Solid substrates prepared to minimum Level 3 finish; clean, dust-free, dry. All gaps, joins, and cracks taped before installation. Very porous surfaces sealed prior to adhesive application. Gloss/semi-gloss finishes lightly sanded. Wall or ceiling substrate.
Performance Metrics
Acoustics
NRC 0.15 (ASTM C423)
Antimicrobial Note
Disinfect with isopropanol or ethanol diluted to 70% with water, or quaternary ammonium compounds. ASTM G21-15 tested: Growth Rating 0 — does not promote growth of molds and mildew.
Crocking
ISO 105-X12:2016 - Dry rating: 4-5 (out of 5); Wet rating: 4-5 (out of 5)
Flammability
ASTM E84 Class A, FS:20 SD:50 (test 01.04913.01.206a); CAN/ULC-S102.2
Light Blocking
Complete
Maintenance
Light vacuuming regularly prevents dust buildup. Clean marks with mild detergent + rinse + blot. Spot clean only; no stiff brush or solvents. Disinfect with 70% isopropanol or ethanol, or quaternary ammonium compounds.
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, Declare Product Label, Declare Product Label - LBC Red List Free, Low Emitting/Low VOC
Climate Health
Climate Impact
Environmental Product Declaration (EPD), ISO 14001 Environmental Management System (EMS), SCS Carbon Neutral Certification
