Glue down. Also available with QuickStix® pre-applied adhesive. Heat welding is recommended for healthcare and high traffic applications
Recommended Adhesive
Porous & Non-porous Substrates: V-95 Full Spread, 2-part Epoxy; MoistureLoc / Amtico RP-18 Full Spread, One-Component; V-88 / Amtico PSA Full Spread, Transitional Pressure Sensitive; XpressStep for LVT & Sheet Vinyl Full Coverage Spray
Performance Metrics
Abrasion Wear Resistance
ISO 4918 Rolling Resistance/ Castor Chair - 25,000 Cycles, No significant change
Acoustics
ASTM E492 - IIC 50 (6in concrete with drop ceiling); ASTM E90 - STC 63 (6in concrete with drop ceiling)
ADA
Passes ADAG (American Disability Act Guidelines)
Classification
ASTM F1303 Type I, Grade 1, Class B
Color Stability From Heat
Passes ASTM F1514 <8 Delta E color change
Compression
ASTM F970 Static Load Residual Indent = 0.005 in; ASTM F970 Static Load (Modified) - 2,000 PSI, Residual Indent less than or equal to 0.005 in; ASTM F1914/F1303 Short Term Residual Indentation Must be = 0.012 in
Flammability
ASTM E648 Flooring Radiant Panel - Class 1, Greater than or equal to 0.45 watts/cm2; ASTM E662 Smoke Density - Less than or equal to 450
Flexural Strength
ASTM F790 - 1/4in Mandrel - No Crack/Break - Passes
Light Blocking
Complete
Lightfastness
Passes ASTM F1515 <8 Delta E color change
Slip Resistance
Passes ASTM C1028 - = 0.5 Leather; 0.6 Rubber
Sustainability
Human Health
Human Health Impact
SCS Global FloorScore Certified, CDPH Standard Method v1.2-2017, Low Emitting/Low VOC, Health Product Declaration (HPD), Phthalates free
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
ISO 14001 Environmental Management System (EMS), Sustainability Action Plan, ESG/CSR, Environmental Product Declaration (EPD), UN Global Compact
Emissions
105% Cradle to Gate (A1-A3)
GWP Functional Unit
kg CO2e/m2
LCA Optimization Plan
false
Ecosystem Health
Ecosystem Health
ISO 14001 Environmental Management System (EMS)
Social Health & Equity
Organizational Commitments
UN Global Compact, ISO 14001
Social Equity Impact
UN Global Compact
Sustainability Action Plan
ESG/CSR
Circular Economy
Circular Economy
Environmental Product Declaration (EPD), Health Product Declaration (HPD)
