Limited 12 Year Commercial Warranty, Limited 12 Year Quantum Guard Elite® Wear Warranty
Material & Finish
Construction
Heterogeneous
Content
Non-Ortho Phthalate Vinyl
Finish
Quantum Guard Elite®
Format
Roll
Availability & Procurement
Availability
Typically Stocked, Stocked in North America
City Of Origin
Salem
Country Of Origin
United States
Lead Time
Please contact your sales rep for details
Manufacturing Location
Salem, NJ
Order Increments
6ft (30-50 sq yds per roll), 9ft (30-75 sq yds per roll), 12ft (30-100 sq yds per roll)
Technical Specifications
Wear Layer Thickness
0.020in (0.51 mm)
Applications & Usage
Application Filter
Flooring
Installation
Glue down. Also available with QuickStix® pre-applied adhesive. Heat welding is recommended for healthcare and high traffic applications
Performance Metrics
Abrasion Wear Resistance
ISO 4918 Rolling Resistance/ Castor Chair - 25,000 Cycles, No significant change
Acoustics
ASTM E492 - IIC 50 (6in concrete with drop ceiling); ASTM E90 - STC 63 (6in concrete with drop ceiling)
ADA
Passes ADAG (American Disability Act Guidelines)
Classification
ASTM F1303 Type I, Grade 1, Class B
Color Stability From Heat
Passes ASTM F1514 <8 Delta E color change
Compression
ASTM F970 Static Load = 0.005in; ASTM F970 Static Load (Modified) - 2,000 PSI, Residual Indent less than or equal to 0.005in; Passes ASTM F1914
Flammability
ASTM E648 Flooring Radiant Panel - Class 1, Greater than or equal to 0.45 watts/cm2; ASTM E662 Smoke Density - Less than or equal to 450
Flexural Strength
ASTM F137 - 1/4in Mandrel - No Crack/Break
Light Blocking
Complete
Lightfastness
Passes ASTM F1515 <8 Delta E color change
Slip Resistance
Passes ASTM C1028 - ≥ 0.5 Leather; 0.6 Rubber
Sustainability
Human Health
Human Health Impact
SCS Global FloorScore Certified, Phthalates free, Low Emitting/Low VOC, CDPH Standard Method v1.2-2017
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
Environmental Product Declaration (EPD), Sustainability Action Plan, UN Global Compact, CARB Compliant, ISO 14001 Environmental Management System (EMS), ESG/CSR
