20 Year Commercial Warranty with approved adhesive
Material & Finish
Construction
Heterogeneous Sheet
Content
Non-Phthalate Vinyl
Finish
Diamond 10® Technology
Format
Roll
Availability & Procurement
Availability
Typically Stocked, Stocked in North America
City Of Origin
Stillwater
Country Of Origin
China
Manufacturing Location
China
Order Increments
6.3 lbs./sq.yd. (3.375 kg/m2) per Carton
Technical Specifications
Overall Thickness
2
Size
6 ft x up to 96 ft, 9 ft x up to 72 ft, 12 ft x up to 72 ft
Wear Layer Thickness
0.020 in. (0.50 mm)
Applications & Usage
Application Filter
Flooring
Installation
Full spread adhesive
Performance Metrics
Abrasion Wear Resistance
Meets EN660-2
ADA
Meets ADA Standards for Accessible Design Chapter 3 Section 302.1 - Floor surfaces shall be stable, firm and slip-resistant
Classification
ASTM F1303, Type I, Grade 1, Class B
Color Stability From Heat
Meets ASTM F1514 with requirement of Delta E less than or equal to 8
Compression
Meets ASTM F1914 - Less than or equal to 0.012 in; Meets ASTM F970 Static Load Resistance - Less than or equal to 0.005 in. (0.13 mm) at 175 psi; Meets ASTM F970 Static Load Resistance - Less than 0.005 in
Flammability
Meets ASTM E648 with requirement of 0.45 W/cm2 or more Class I; Meets ASTM E662 Smoke Evolution - 450 or less; CAN/ULC S-102.2 Flame Spread - 65, Smoke Developed - 200
Light Blocking
Complete
Lightfastness
Meets ASTM F1515 with requirement of Delta E less than or equal to 8
Maintenance
Polish Optional
Slip Resistance
Meets ASTM D2047/UL 410 Static Coefficient of Friction - Greater than or equal to 0.5
Sustainability
Human Health
Human Health Impact
SCS Global FloorScore Certified, Health Product Declaration (HPD), CDPH Standard Method v1.2-2017
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
Environmental Product Declaration (EPD)
GWP Functional Unit
kg CO2e/m2
Circular Economy
Circular Economy
Environmental Product Declaration (EPD), Health Product Declaration (HPD)
